After a while, the drive belt on your kBox may need a trim. Here’s how to do it:
If wear or damage occurs close to the end of the belt, you need to trim the belt by cutting off the damaged end and reattach the new end. Follow this procedure for the kBox4 with the help of the standard Tool Bag you received with your kBox4 system:
- Unwind the entire belt from the shaft.
- Use the Locking Pin Removal Tool to push the Belt through the shaft and remove the Locking Pin.
- Cut off the damaged part of the Belt. (If the remaining part is too short, you may need to replace it.)
- Wrap Belt around the Locking Pin and pull the Belt and Pin into the wider groove in the shaft.
- The Belt automatically locks into the grove when you pull it firmly.
- See this video for the kBox4 (same as visible on this page).
- See this video for the kPulley2.
- For previous versions of the kBox, see the kBox3 maintenance video guide.
